VRS200 Grapple
VRS200 Grapple
Powerhand VRS Grapples, designed to emulate a pair of surgical tweezers, are equipped with narrow jaws and a specially designed grip profile providing a unique ability to pick and select materials and components with absolute precision.
Powerhand VRS grapple jaws have a high gripping force and can easily access difficult-to-get-to areas in demolition work and vehicle recycling and waste recycling operations resulting in a higher yield.
Combined with a slimline design for greater visibility from the operator’s seat and a high gripping force with a high torque rotational unit, Powerhand VRS grapples offer the ultimate in strength and dexterity as a pick and select excavator tool.
VRS200 grapples are designed for use on machines in the 18 to 25 tonne weight class. Equipped with a grapple shear, with maximum blade opening of 400mm, the VRS200 grapple offers enhanced functions for recycling and demolition operations.
Powerhand VRS grapples are also available in models VRS140 (14-18 tonne excavators) and VRS180 (16-25 tonne excavators).
Specification
| VRS200 Grapple | |
| Min. Base Machine Weight Class | 18000kg |
| Max. Base Machine Weight Class | 25000kg |
| Grapple Shear Max. blade opening | 400mm |
| Overall Height | 2525mm |
| Max. Jaw Opening | 1050mm |
| Weight | 1840kg |
| Rotation Unit | XR600 Vane Motor |
| Torque | 7,000Nm @ 250bar |
| RPM | 20RPM @ 40l/min |
Gallery
